18-inch Gate Valves
Four cast iron Econosto DN-450 18-inch gate valves available for sale from Saipem. These valves can be used for cold and hot fresh water, seawater, lubricating oil, steam etc in low-pressure applications (note color photo is from model DN-350). Certifi...
Details
• Pressure rating: 2 bar - 150 degrees for steam and sea water, 6 bar - 120 degrees for other media
• Internal diameter: 450mm
• Flange diameter: 615mm
• Weight: 331 kg
• Bronze seat
• Flanged ends
• Bolted bonnet
• Inside screwed stem
• Non-rising stem
• Non-rising handwheel
• Solid wedge
• More details on drawing attached and on www.econosto.nl/products (gate-valve-econ-fig-317/576800)
• Internal diameter: 450mm
• Flange diameter: 615mm
• Weight: 331 kg
• Bronze seat
• Flanged ends
• Bolted bonnet
• Inside screwed stem
• Non-rising stem
• Non-rising handwheel
• Solid wedge
• More details on drawing attached and on www.econosto.nl/products (gate-valve-econ-fig-317/576800)
