30Te A-Frame

Name: 30Te A-Frame
Brand: tbc/unknown
Availability: InStock

30Te A-Frame available for sale immediately. This is unit is unused having been built for a cancelled project. It will require one month to commission and FAT. See attached specification and GA drawings for further details.

Details

Technical specifications

Classification: Safe Area
Type: Hydraulically powered A-Frame
Certification/standard : Designed in accordance with DNVGL-ST-0378
Dynamic Amplification Factor : 2.5
Safe Working Load : 30 t
Operational Dimensions : Length 22600 mm, Width 13450 mm, Height 13680 mm (arc max)
Weight: 76 400 kg
Operating temperature: -10°C up to +45°C
Deployed reach ≥ 8200 mm
Clear spacing between legs ≥ 11550 mm

NOTE: "Requires 1 month to commission & FAT"

See attached specification for additional information or contact seller.

Show less

MAIN DETAILS

Manufacturer

tbc/unknown

Price

Contact seller

LISTING ID

2645

Year built

2021
