MAN B&W 14V 32/40 diesel genset package

Equipment details

• Diesel Genset Package: 6 identical sets, each comprising:
  • Engine: (1x) MAN B&W 14V 32/40 Diesel Engine
    • Power: 6720 kW (approx. 9011 hp)
    • Speed: 720 rpm
  • Alternator: (1x) LDW AC Generator
    • Power: 6720 kW
    • Output: 11,000 V @ 60 Hz
    • Speed: 720 rpm
• VFD System (Siemens SIPLINK)
  • Propulsion VFDs:
    • (6x) Units: Total continuous power of 33 MW
    • Output: 2 kV
  • Drilling VFDs:
    • (29x) Units: Total continuous power of 24 MW
    • Output: 1.1 kV
• Compressed Air Systems
  • High Pressure (HP): (2x) Greenfield D63-A Electric Compressors
    • Capacity: 19,780 ft³/hr @ 4,000 psi
    • Driver: 150 hp electric motors
  • Medium Pressure (MP) / Rig Air: (4x) Ingersoll Rand HXPE250-2S Electric Compressors
    • Capacity: 54,746 ft³/hr @ 150 psi
    • Driver: 250 hp electric motors
    • (2x) Ingersoll Rand Air Dryers included with the MP system.
• Emergency Generator (C2)
  • Engine: (1x) STX-MAN-B&W 14-Cylinder Diesel
    • Power: 2310 kW (approx. 3098 hp)
    • Speed: 720 rpm
  • Alternator: (1x) Hyundai Brushless AC Generator
    • Power: 2100 kW
    • Output: 480 V @ 60 Hz
  • Note: Capable of back-feeding the main 11kV bus.
